Product informatie
Omschrijving
- Low voltage-temperature coefficient improves high-temperature operation.
- Exceptional low-light performance and high sensitivity to light across the entire solar spectrum.
- 25-year limited warranty on power and performance.
- 5-year limited warranty on materials and workmanship.
- Sealed, waterproof, multi-functional junction box provides a high level of safety.
- High-performance bypass diodes minimize power drop caused by shading.
- Advanced EVA (ethylene vinyl acetate) encapsulation system with triple-layer backsheet meets the most stringent safety requirements for high-voltage operation.
- A sturdy, anodized aluminum frame allows modules to be easily mounted on the roof using a variety of standard mounting systems.
- Highest quality tempered glass with high transmission provides improved stiffness and impact resistance.
- Powerful models with pre-wired quick-connect system with solar connectors.
Specificaties
Afmetingen
1485x668x30mm
Gewicht
11,0 kg
Cell type
Monokristallijn
Aantal cellen
36 cellen
Max wattage (Pmax)
185 Watt
Max spanning (Vmpp)
19,68 volt
Max stroom (Imp)
9,41 Ampère
Nullastspanning
24,11 Volt
Kortsluitstroom
9,91 Ampère
Max systeemspanning
1000 Volt (IEC)
Bedrijfstemperatuur
-40°C tot +85°C
Vermogensgarantie
10 jaar 90% + 25 jaar 80%
Garantie
5 jaar
