Product informatie
Omschrijving
- Simultaneous charging of 2 batteries (starter and house).
- Low-cost PWM controller.
- Internal temperature sensor.
- Three-stage battery charging (bulk, absorption, float).
- Protected against overcurrent.
- Protected against short circuit.
- Protected against reverse polarity connection of the solar panels and/or battery.
- With low load voltage disconnect output.
- Automatic recognition of battery voltage 12/24V
Specificaties
Systeemvoltage
12/24 Volt
Nominale laadstroom
10A
Nominale pv vermogen
12V/120W, 24V/240W
Maximale PV-nullast-spanning
30V/55V
Communicatie
8-pin RJ-45
Afmetingen
53×76×37mm
Gewicht
0,24kg
Bedrijfstemperatuur
-35 tot +55°C
Garantie
2 jaar
