Charge controller MPPT 100-30 Smartsolar - Victron energy

Product information

Product description

Ultra-fast Maximum Power Point Tracking. By constantly monitoring the voltage and current produced by your solar panels, MPPT technology ensures that the available power of your panels is fully utilized and harvested for storage. The advantage of this is most noticeable when the sky is partly cloudy and the light intensity is constantly changing.

Remote monitoring and control

Remotely control and monitor the extensive features of your BlueSolar MPPT charger by connecting a Bluetooth dongle and pairing it with your smartphone or other device using VictronConnect.

Tax output

The intelligent load output function prevents damage caused by batteries running flat. You can configure the voltage at which SmartSolar disconnects the load, preventing excessive discharge of your batteries. And the clever thing about it: SmartSolar attempts to recharge the battery to 100% every day. If it fails to do so - during periods of bad weather - it increases the disconnect voltage daily until charging is successful. We call this function BatteryLife, because it keeps the battery in good condition and extends its lifespan.

Product specifications

System voltage: 12/24 Volt
Nominal charging current: 30A
Nominal PV power: 12V/440W, 24V/880W
Maximum PV no-load voltage: 100V
Communication: VE-Direct/Bluetooth
Dimensions: 130x186x70mm
Weight: 1.3kg
Operating temperature: -30 to +60°C
Warranty: 5 years
